| Critical Note:
400EX Head studs will pull the threads loose in the cylinder anytime that the cylinder gets too hot breaking down the aluminum. There are several causes of this including overheating of the cylinder during resleaving and poor matching of fuel octane to the engine. Critical Note: These heavy duty studs cannot be used if the cylinder was drilled and tapped for Helicoils or drilled and tapped for any other oversize studs with a differant thread diameter and pitch.
|
TRX400EX Heavy Duty Head Studs $59.95 These head studs are for repairing the 400EX cylinder after the thread in the cylinder are damaged or can be installed in a new cylinder to help prevent head gaskets failing as quickly. They have shown to have over 70% more holding strength then the stock head studs due to the increased diameter and the longer threaded area on the studs. They can be installed with the cylinder on the quad but we prefer to machine the cylinder for the new studs on a mill for better accuracy. 400EX Heavy Duty Stud Kit - $59.95 Roll form tap $39.95 Stud Installation - $55.00
HOW TO BUY THEM Call us at 330-674-7122 Buy them thru any of our authorized retailers. Or order them online from one of our authorized retailers. Online ordering - Click here |
Stock vs. Heavy duty
Stud kit
|
|
Installation
Instructions
You
need to first drill and tap the cylinder to accept the new studs. Hole machining 7/16-inch
course thread. Be
sure to hone cylinder after studs are installed. Install
the new studs using Permatex sleeve retainer on the threads. Be
sure to install to the correct height. The
studs must be the correct distance out of the top of the cylinder. Front
– 2.436” Rear
– 3.188” Sides – 1.929”
|
